Foundation free concrete mixing plant can avoid the process of design, construction and installation of foundation, which saves customers the time and cost of building the station. However, some customers can't help asking "what are the advantages of foundation free concrete mixing plant and why is it so good?"
The foundation free concrete mixing plant is composed of aggregate batching system, lifting hopper, concrete mixing plant unit, metering unit, water admixture tank, control room, air control system, electrical system, etc.
1. The aggregate batching system adopts frame structure and is placed on a large chassis as a whole, which not only increases the stability of the equipment, but also increases the overall stress area of the equipment. The aggregate batching system is connected with the concrete mixing plant unit through the middle track frame;
2. The water admixture tank and the control room are welded from formed plates, installed together and placed under the concrete mixing plant unit as equipment legs, which increases the overall stress area of the equipment and improves the stability of the equipment;
3. The concrete mixing plant unit and metering unit adopt frame structure, which are connected together by bolts, and the walking platform is connected by hinge. During transportation, it can be folded along the hinge point to reduce the transportation space;
4. The electrical system adopts the form of quick plug connector, which improves the installation cycle of the equipment;
5. The underframe can be installed through different connection forms, and different stabilized soil mixing station can be designed conveniently according to the customer's site conditions.
