Diesel Concrete Mixer

Diesel Concrete Mixer

Mixing equipment
  • Strength business
  • Quality assurance
  • Perfect technology
Notice: Shandong China Coal Concrete Mixer Co., Ltd. is a heavy industry enterprise specializing in the production of large and medium-sized concrete mixers, concrete mixing station, stabilized soil mixing stations, etc.

Diesel Concrete Mixer

Product introduction

Concentrate on details and be good at heart.

  • Quality material selection
  • User friendly design
  • Efficient operation
  • factory outlet
  • Simple structure
  • High production efficiency
  • Light weight
  • Good mixing quality
Diesel Concrete Mixer

Diesel concrete mixer has the advantages of reliable transmission, low noise, low energy consumption, compact structure, smooth operation, simple operation, good mixing quality and high productivity.

  • Diesel concrete mixer
  • Diesel concrete mixer
  • Diesel concrete mixer

High cost performance, easy to move pulley

Diesel Concrete Mixer

Product advantage

Is the original mixer still in use?

After suffering, getting dirty or not living

  • Diesel Concrete Mixer
    Too heavy
    to move
  • Diesel Concrete Mixer
    Single stirring
    function
  • Diesel Concrete Mixer
    Single use
    scenario
Advantage one Motor advantages

Imported pure copper motor with high quality, high temperature and high voltage resistance, simple installation and easy operation.

Diesel Concrete Mixer

High efficiency
Diesel Concrete Mixer
Advantage two Dominant material advantage

The drum is made of thick steel plate, and the support frame is made of high quality thick seamless steel pipe. It is made of welded, polished and baked paint, which is strong and durable.

  • Diesel Concrete Mixer
  • Diesel Concrete Mixer
  • Diesel Concrete Mixer
Advantage three Efficiency advantage

The power of the motor is stable, which drives the tank to rotate evenly, using the principle of inertia.It achieves fast mixing speed, even mixing, fast, convenient and clean discharging.

Hopper Super Large
Cylinder Block
tyre All copper
motor
Coil Discharge
port
Supporting
frame legs

Diesel Concrete Mixer

Product parameters
Diesel Concrete Mixer technical parameter
Capacity of loading(L) 560L Power source Diesel engine
Engine power 8.82KW Productivity 10-14m ³/h
Mixing and raising power 12HP Traction speed 10-15km/h
Traction speed 10-15km/h Entire machine weight 2,400kg
Hopper lifting model Hydraulic tipping hopper External dimension 2766×2140×3170mm
Model S195 Cylinder bore 95mm
Piston stroke 115mm 1 hr. rate output 9.7kw(13.2HP)/2200rpm
12 hr. rate output 8.8kw(12HP)/2200rpm Piston displacement 0.815liter
Compression ration 20:01 B.M.E.P 650kpa
Specific fuel consumption ≤251g/kw•h Type of cooling Water evaporative
Type of starting Electric Net weight ≤145kg
Type of fuel injection UI-00 Type of nozzle coupling U4-3
